Sercomm 10G Ethernet SFP Transceivers - Silver
The THCPRJ-0088-0AAE copper transceiver module is a high performance integrated duplex data link for bi-directional communication over copper cable. It is specifically designed for high speed communication links that require 10 Gigabit Ethernet over Cat 6a/7 cable. This is the first SFP+ transceiver that offers 10 Gb/s communication over this type of media.
Up to 10Gb/s bi-directional data links
Hot-pluggable SFP+ footprint
Fast Retrain EMI Cancellation Algorithm
Fully metallic enclosure for low EMI
Low power dissipation(2.5W max @ 30m)
Compact RJ-45 connector assembly
I2C 2 Wire Serial Interface for Serial Id and PHY Registers
Auto-negotiates with other 10GBase-T-NC PHYs
Automatic Detection and Correction of Wiring and Polarity Swaps
Robust Die Cast Housing
Bail Latch Style ejector mechanism
Unshielded and Shielded cable support
Supports Links up to 30m using Cat 6a/7 Cable
Operating case temperature: 0℃ to 85℃
RoHS Compliance
Application
10 Gigabit Ethernet over Cat 6a/7 cable
Standards
Compliant With IEEE 802.3az
Compliant With SFF-8431 and SFF-8432 MSA
Compliant With SFF-8472
